Field Emission Scanning Electron Microscope (FESEM)

Model : Quanta FEG 250

Resolution : 1nm on standard samples (Au nanoparticles on C)

Magnification : Minimum: 100x to Maximum: 3,00,000x (STEM) and 6,00,000x (ETD)

1. Capabilities:

        a. High vacuum mode :

i.          Everheart Thornley Detector (ETD)

ii.        Concentric Backscatter Detector (CBS)

iii.       Scanning Transmission Electron Microscopy (STEM) detector



        b. Low Vacuum mode & Environmental mode :

i.          Large Field Detector (LFD)



2. Energy Dispersive X-ray spectroscopy :

        a. Normal Energy Dispersive X-ray Spectrometer (EDS)

        b. Mapping:

1.     Line mapping

2.     Area mapping



Sample Preparation :

        1. Sputter coater - LEICA EM ACE 200

        2. Critical Point Drying (CPD) - LEICA EM CPD 300

        3. Ultra Microtome - LEICA EM UC7

        4. Tissue processor - LEICA EM TP

         5. Heater - LEICA EM MP


User Charges:

Note:

* Maximum 1h will be provided by operator per sample. A maximum slot time of 3 hours will be provided per user.
** For Fixation and Dehydration of biological sample, only 150 µl Osmium tetroxide per sample will be provided by operator. User is expected to do the Fixation and Dehydration of his or her biological sample.

Additional charges are applicable as follows:
1. Additional charges for FESEM Image analysis (A maximum of 15 min will provided by the operator per request for an image).
2. Additional charges for EDX point analysis.
3. Additional charges for EDX Mapping.
4. Additional Charges for STEM Image analysis.
5. Sputter coating charges are applicable only for non-conducting samples.

Allotment of slots will be at the discretion of the operator after discussions with the user. Any special analysis request (not included in the above list) may be discussed with the operator for feasibility and will be charged accordingly after discussions with in the In-Charge, CSIF, BITS Pilani K K Birla Goa Campus.


Sample Requirements for FESEM /STEM

  • Sample should be dry & non-magnetic.
  • Powder/metal/thin-film samples are accepted for analysis. If powder samples have > 100 nm particle, user is expected to dissolve the same in appropriate solvent and then drop cast/spin coat it on conducting substrate, e.g. Copper, Aluminum foil, silicon substrate before handling for analysis. This can be discussed with the operator.
  • Biological & liquid samples should be fixed and coated/drop-casted on a conducting substrates (1cm x 1cm) and dried well before the allotted slot timings.
  • Quantity of sample required (Powder samples only): 10 mg (minimum).
Liquid Chromatography-Mass Spectrometry (LCMS)


  • Agilent Technology
  • Model 6460 Triple Quadrupole LC/MS consists 1290 infinity II Binary Pump, auto sampler, and Diode array detector. The supported ion sources are ESI and APCI.
  • Femtogram-level of detection and quantitation.

Application for :

  1. Food safety studies
  2. Environmental studies
  3. Drug discovery
  4. Forensic
  5. Bioanalysis
  6. Protein
  7. Academia
  8. Clinical
  9. Pharmaceutical
  10. Veterinary drug

User Charges:

Note:

1.     Solvents like DMSO, DMF and THF cannot be used. The integrity of sample to be injected into the instrument will be at the sole discretion of the operator. It is the responsibility of the user to discuss the same with the operator prior to analysis. Impure and crude samples are unlikely to be analyzed.

2.     All samples will be discarded after use. In case the user wishes to retain his or her sample after analysis, this may be informed to the operator prior to analysis.

3.     ESI /APCI-MS and LC-MS/MS are possible only in methanol, acetonitrile or water.

4.     5-10 mg sample, LC conditions & LC trace for LC-MS and LC-MS/MS is required.

5.     MS-DS (Material Safety Data Sheet) of the sample must be provided with analysis request.


Allotment of slots will be at the discretion of the operator after discussions with the user. Any special analysis request (not included in the above list) may be discussed with the operator for feasibility and will be charged accordingly after discussions with in the In-Charge, CSIF facility, BITS Pilani K K Birla Goa Campus.

Confocal Microscope

Equipment details:

*Model : Olympus Corporation FV3000

* Double deck Motorized Frame with Motorized sextuple revolving nosepiece

* Diode lasers: 405, 488, 561, 514 & 640 nm

* Infinity corrected objectives 1.25X, 10X, 20X, 40X, 60X & 100X.

* Live tissue and cell samples in CO2 incubator.

* Stroke: 10.5mm, Minimum increment: step size of 0.01μm,

* SMART Touch Panel Controller Switch

* Automatic controls for switching of optical Components, aperture adjustment and exposure.

User Charges



Raman Spectrometer

LAB RAM HR Horiba France

·       Spectral Range 200 - 2100 nm

·       Microscope with three objective; 5x, 10x, and 100x.

·       Spectrometer with two gratings: 600 and 1800 gr/mm.

·       Available Lasers:

(A) 325 nm He-Cd laser 25 mW

(B) 532 nm Nd-YAG laser 100 mW

(C) 633 nm HeNe laser 17 mW and

(D) 785 nm diode laser 100 mW.

·       Spectral searching and analysis software (KnowItAll Horiba Edition)

·       Motorised x-y stage

·       Three positions - 100 % Transmission, 100 % Reflectance, 50 % Transmission

·       Lateral Resolution ~ 5 μm

User Charges:

X-Ray Diffractometer (XRD)

Equipment details:

Bruker D8 Advance

* Micro-structure & crystal structure analysis

* Powder diffraction applications

* Quantitative phase analysis

* Low angle diffraction

* High temperature (up to 1600 C) attachment

User Charges:



NMR

Equipment details:

  • Bruker Avance Neo 500 MHz
  • Liquid and Solid state NMR
  • RT Probe plateform, TopSpin controlled console
  • Gradient control with a resolution of 12.5 ns

User Charges:

Solvent Charges:
For D2O, CDCl3,100/- per sample
For DMSO, 100/- per sample
Zeta / Nano Particle Analyzer

Equipment details:

Model : NanoPlus with NanoPlus AT (Auto titrator)

* Particle sizing by Dynamic Light Scattering

*Zeta potential determination of Particles/powder dispersed in suitable liquid Thin membrane by electrophoretic Light Scattering

User Charges:
